ASUS Pro business motherboards provide enhanced features to smooth your IT operations, including comprehensive system protection, 24/7 stability and reliability and an improved management suite for easier customization. Known as the world's biggest and best-known motherboard brand, ASUS provides world-class after-sales service and guaranteed long-term availability to maximize your investment over the product life cycle and offers a high-quality, TCO-optimized solution for your business computing-needs.
Specificaties
| Design | |
|---|---|
| Kleur van het product | Green |
| Cooling type | Passive |
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Maximum resolution | 3840 x 2160 |
| Parallel processing technology support | Not supported |
| Processor socket | LGA 1851 (Socket V1) |
| Compatible processor series | Intel Core Ultra (Series 2) |
| Supported processor sockets | LGA 1851 |
| Geheugen | |
|---|---|
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| ECC-compatibiliteit | non-ECC |
| Maximum internal memory | 256 |
| Ondersteunde geheugenkloksnelheid (max) | 8666 |
| Niet gebufferd geheugen | Ja |
| Maximaal intern geheugen per slot | 64 |
| Netwerk | |
|---|---|
| Ethernet LAN | Ja |
| Ethernet interface type | Gigabit Ethernet |
| Wi-Fi | Geen |
| Poorten & interfaces | |
|---|---|
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C | 1 |
| Gewicht en omvang | |
|---|---|
| Breedte | 244 |
| Diepte | 244 |
| Inhoud van de verpakking | |
|---|---|
| Meegeleverde kabels | SATA |
| Screws included | Ja |
| Kenmerken | |
|---|---|
| Component for | PC |
| Motherboard chipset | Intel B860 |
| Audio-uitgangskanalen | 7.1 |
| Moederbord form factor | Micro ATX |
| Moederbord chipset familie | Intel |
| Opslag-controllers | |
|---|---|
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2,SATA III |
| Maximum aantal HDD's per behuizing | 4 |
| Number of storage drives supported | 6 |
| RAID support | Ja |
| RAID levels | 0,1,5,10 |
| Interne aansluitingen | |
|---|---|
| USB 2.0 aansluitingen | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen | 1 |
| Number of SATA III connectors | 4 |
| Aansluiting voor audiopaneel aan voorzijde | Ja |
| ATX Power connector (24-pin) | Ja |
| Aansluiting voor CPU koeler | Ja |
| TPM connector | Ja |
| 12V vermogen-connector | Ja |
| Voorpaneel-connector | Ja |
| Aantal CPU-ventilatoraansluitingen | 1 |
| Aansluitingen voor behuizingsventilatoren | 2 |
| EPS power connector (8-pin) | Ja |
| Aantal EPS-voedingsaansluitingen (8-pins) | 1 |
| USB 3.2-connectoren (3.1 Gen 2) | 1 |
| Chassis intrusion aansluiting | Ja |
| COM aansluitingen | 2 |
| Aansluitingen achterzijde | |
|---|---|
| Headphone outputs | 1 |
| Microphone in | Ja |
| PS/2 poort(en) | 2 |
| Lijningang | Ja |
| BIOS | |
|---|---|
| BIOS type | UEFI AMI |
| Grootte BIOS-geheugen | 256 |
| Uitbreidingsmodules | |
|---|---|
| PCI Express x16 (Gen 5.x) slots | 1 |
| Aantal M.2 (M) slots | 2 |
| 1e M.2 grootste sleutelgrootte | 2280 |
| 1e M.2 hoogste PCI Express-generatie | 5.0 |
| 2e M.2 grootste sleutelgrootte | 2280 |
| 2e M.2 hoogste PCI Express-generatie | 4.0 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x1 (Gen 4.x) sleuven | 1 |
