Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
Specifications
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Parallel processing technology support | Not supported |
| Processor socket | LGA 1700 |
| Compatible processor series | Intel Celeron,Intel Core i3,Intel Core i5,Intel Core i7,Intel Core i9,Intel Pentium Gold |
| Supported processor sockets | LGA 1700 |
| Maximaal intern geheugen ondersteund door processor | 128 |
| Geheugen | |
|---|---|
| Supported memory types | DDR4-SDRAM |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| ECC-compatibiliteit | non-ECC |
| Supported memory clock speeds | 2133,2400,2666,2933,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000,4133,4266,4300,4400,4500,4600,4700,4800,4933,5000,5133,5333 |
| Maximum internal memory | 128 |
| Ondersteunde geheugenkloksnelheid (max) | 5333 |
| Niet gebufferd geheugen | Yes |
| Ondersteunde geheugenmodule capaciteiten | 1GB,2GB,4GB,8GB,12GB,16GB,32GB |
| Grafisch | |
|---|---|
| On-board graphics card | No |
| Number of displays supported | 4 |
| Netwerk | |
|---|---|
| Ethernet LAN | Y |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Wi-Fi | N |
| Poorten & interfaces | |
|---|---|
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| DisplayPorts quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Accu/Batterij | |
|---|---|
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery type | CR2032 |
| Gewicht batterij | 3 |
| Lithiumgewicht per batterij | 0.07 |
| Aantal batterijcellen | 1 |
| Gewicht en omvang | |
|---|---|
| Width | 244 |
| Depth | 244 |
| Height | 35 |
| Inhoud van de verpakking | |
|---|---|
| Bundled software | Norton Internet Security |
| Batterijen inbegrepen | Yes |
| Kenmerken | |
|---|---|
| Country of origin | China |
| Component for | PC |
| Motherboard chipset | Intel B760 Express |
| Audio-uitgangskanalen | 7.1 |
| Moederbord form factor | Micro ATX |
| Moederbord chipset familie | Intel |
| PC gezondheids monitor | FAN,Temperature,Voltage,Water cooling |
| Verpakking | |
|---|---|
| Package width | 265 |
| Package depth | 265 |
| Package height | 54 |
| Package weight | 990 |
| Logistieke gegevens | |
|---|---|
| Products per shipping (inner) case | 1 |
| Prestatie | |
|---|---|
| DirectX version | 12.0 |
| Warranty period | 3 |
| HDCP | Y |
| Minimale systeemeisen | |
|---|---|
| Windows operating systems supported | Windows 10,Windows 11 |
| Opslag-controllers | |
|---|---|
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2,SATA III |
| Maximum aantal HDD's per behuizing | 4 |
| Number of storage drives supported | 6 |
| RAID support | Y |
| RAID levels | 0,1,5,10 |
| Interne aansluitingen | |
|---|---|
| USB 2.0 aansluitingen | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen | 1 |
| Number of SATA III connectors | 4 |
| Aansluiting voor audiopaneel aan voorzijde | Yes |
| ATX Power connector (24-pin) | Yes |
| Aansluiting voor CPU koeler | Yes |
| TPM connector | Yes |
| Voorpaneel-connector | Yes |
| Aansluitingen voor behuizingsventilatoren | 3 |
| EPS power connector (8-pin) | Yes |
| Serial port headers | 1 |
| RGB LED-aansluitrail | Yes |
| Total number of SATA connectors | 4 |
| S/PDIF uitgang | Yes |
| Parallele connector | Yes |
| Aansluitingen achterzijde | |
|---|---|
| Headphone outputs | 1 |
| PS/2 poort(en) | 1 |
| Lijningang | Yes |
| BIOS | |
|---|---|
| BIOS type | UEFI AMI |
| Grootte BIOS-geheugen | 128 |
| ACPI version | 5.0 |
| Clear CMOS jumper | Yes |
| Versie Desktop Management Interface (DMI) | 2.7 |
| Systeem Management BIOS (SMBIOS) versie | 2.7 |
| Uitbreidingsmodules | |
|---|---|
| Aantal M.2 (M) slots | 2 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 1 |
