Specificaties
| Design | |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 120 |
| Number of fans | 1 |
| Fan speed | 0 - 2100 |
| On/off switch | Ja |
| Poorten & interfaces | |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| PCI Express power connectors (6+2 pin) | 3 |
| CPU power connector (4+4 pin) | Ja |
| CPU P4 connector (4-pin) | 1 |
| Number of SATA power connectors | 6 |
| PCI Express power connectors (12-pin) | 1 |
| Cabling type | Non-Modular |
| Energie | |
|---|---|
| Power factor | 0.98 |
| Max output current (+12V1) | 62.5 |
| Total power | 750 |
| AC input voltage | 200 - 240 |
| AC input frequency | 50 |
| Input current | 4 |
| Number of +12V rail(s) | 1 |
| Combined power (+3.3V) | 120 |
| Combined power (+12V) | 750 |
| Combined power (+5V) | 120 |
| Combined power (-12V) | 3.6 |
| Combined power (+5Vsb) | 15 |
| Max output current (+3.3V) | 20 |
| Max output current (+5V) | 20 |
| Max output current (-12V) | 0.3 |
| Max output current (+5Vsb) | 3 |
| Hold time | 17.34 |
| Efficiency | 90 |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit,Surge & inrush,Under voltage |
| Gewicht en omvang | |
|---|---|
| Width | 150 |
| Depth | 86 |
| Height | 140 |
| Weight | 2040 |
| Certificaten | |
|---|---|
| Waste Electrical and Electronic Equipment (WEEE) compliance | Ja |
| Compliance certificates | CB,CE,RoHS,TÜV mark,UKCA,WEEE |
| Verpakking | |
|---|---|
| Package width | 195 |
| Package depth | 268 |
| Package height | 97 |
| Package weight | 2400 |
| Package type | Box |
| Logistieke gegevens | |
|---|---|
| Shipping (inner) case length | 556 |
| Shipping (inner) case width | 311 |
| Shipping (inner) case height | 218 |
| Products per shipping (inner) case | 6 |
| Shipping (inner) case gross weight | 15600 |
| Overige specificaties | |
|---|---|
| Screws included | Ja |
| Cable ties included | Ja |
| Prestatie | |
|---|---|
| Mean time between failures (MTBF) | 100000 |
| ATX version | 3.1 |
| EPS version | 2.92 |
| 80 PLUS certification | 80 PLUS Bronze |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| Noise level | 33.4 |
| Bearing technology | Rifle |
| Technische details | |
|---|---|
| Sustainability certificates | ENERGY STAR,ErP |
| Interne aansluitingen | |
|---|---|
| Peripheral (Molex) power connectors (4-pin) | 1 |
| EPS power connector (8-pin) | Ja |
