Multi-Link Operation (MLO)
Enables devices to simultaneously send and receive data across different frequency bands and channels.
Two 10G PoE++ Ports
Boosts overall throughput and offers flexible deployment with two 10 Gbps PoE++ ports.
Auto Channel Selection and Power Adjustment
Boost WiFi performance and minimize interference for your network.
Intelligent Power Management
Offers more reliable network operation for your business.
Centralized Cloud Management
Manage the whole network locally or from the cloud.
Omada Mesh Technology
More flexible and convenient wireless deployment.△
PoE++ Power
Supports both 12V DC and 802.3bt PoE++ for flexible installations.
Enables devices to simultaneously send and receive data across different frequency bands and channels.
Two 10G PoE++ Ports
Boosts overall throughput and offers flexible deployment with two 10 Gbps PoE++ ports.
Auto Channel Selection and Power Adjustment
Boost WiFi performance and minimize interference for your network.
Intelligent Power Management
Offers more reliable network operation for your business.
Centralized Cloud Management
Manage the whole network locally or from the cloud.
Omada Mesh Technology
More flexible and convenient wireless deployment.△
PoE++ Power
Supports both 12V DC and 802.3bt PoE++ for flexible installations.
Specificaties
| Design | |
|---|---|
| Kleur van het product | White |
| LED-indicatoren | Ja |
| Reset button | Ja |
| Placement | Ceiling,Wall |
| Netwerk | |
|---|---|
| Flow control support | Ja |
| VLAN support | Ja |
| Rate limiting | Ja |
| Poorten & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Ja |
| Energie | |
|---|---|
| DC voltage range | 12 |
| Beveiliging | |
|---|---|
| Access Control List (ACL) | Ja |
| Security algorithms | WPA,WPA2,WPA3 |
| Gewicht en omvang | |
|---|---|
| Breedte | 280 |
| Diepte | 280 |
| Hoogte | 46.5 |
| Inhoud van de verpakking | |
|---|---|
| Quick start guide | Ja |
| Mounting kit | Ja |
| Kenmerken | |
|---|---|
| Quantity per pack | 1 |
| Maximum data transfer rate | 19000 |
| 2.4 GHz | Ja |
| 5 GHz | Ja |
| 6 GHz | Ja |
| Maximum data transfer rate (2.4 GHz) | 1376 |
| Maximum data transfer rate (5 GHz) | 5760 |
| Maximale overdrachtssnelheid van gegevens (6 GHz) | 11520 |
| MIMO | Ja |
| MIMO type | Multi User MIMO |
| Airtime Fairness (ATF) | Ja |
| BeamForming | Ja |
| Frequency band | 2.4 - 6 |
| Automatische kanaalselectie | Ja |
| Automatisch scannen kanalen | Ja |
| Bandbreedteaansturing | Ja |
| Eisen aan de omgeving | |
|---|---|
| Bedrijfstemperatuur (T-T) | 0 - 40 |
| Temperatuur bij opslag | -40 - 70 |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 |
| Luchtvochtigheid bij opslag | 5 - 90 |
| Verpakking | |
|---|---|
| Package type | Box |
| Beheerfuncties | |
|---|---|
| Quality of Service (QoS) support | Ja |
| Antenne | |
|---|---|
| Antenna type | Internal |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Ja |
