TP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.
Specificaties
| Design | |
|---|---|
| Kleur van het product | Black |
| LED-indicatoren | Ja |
| Rack mounting | Ja |
| Netwerk | |
|---|---|
| Link aggregation | Ja |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| 10G support | Geen |
| Flow control support | Ja |
| Spanning tree protocol | Ja |
| Auto-negotiation | Ja |
| VLAN support | Ja |
| Port mirroring | Ja |
| Broadcast storm control | Ja |
| Rate limiting | Ja |
| Number of VLANs | 4094 |
| Auto MDI/MDI-X | Ja |
| Poorten & interfaces | |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Energie | |
|---|---|
| Power supply included | Ja |
| Power consumption (max) | 77.3 |
| Beveiliging | |
|---|---|
| DHCP features | DHCP client,DHCP relay,DHCP snooping,DHCPv6 server,DHCPv6 snooping |
| IGMP snooping | Ja |
| Security algorithms | 802.1x RADIUS |
| Authentication | MAC-based authentication,Web-based authentication |
| Authentication type | RADIUS |
| MAC address filtering | Ja |
| Gewicht en omvang | |
|---|---|
| Breedte | 209 |
| Diepte | 126 |
| Hoogte | 26 |
| Inhoud van de verpakking | |
|---|---|
| Manual | Ja |
| Eisen aan de omgeving | |
|---|---|
| Bedrijfstemperatuur (T-T) | 0 - 40 |
| Temperatuur bij opslag | -40 - 70 |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 |
| Luchtvochtigheid bij opslag | 5 - 90 |
| Heat dissipation | 263.6 |
| Certificaten | |
|---|---|
| Certificering | CE, FCC, RoHS |
| Verpakking | |
|---|---|
| Package type | Box |
| Prestatie | |
|---|---|
| Fanless | Ja |
| Beheerfuncties | |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L2+ |
| Quality of Service (QoS) support | Ja |
| Web-based management | Ja |
| ARP inspection | Ja |
| System event log | Ja |
| MIB support | MIB II (RFC1213) Bridge MIB (RFC1493) P/Q-Bridge MIB (RFC2674) Radius Accounting Client MIB (RFC2620) Radius Authentication Client MIB (RFC2618) Remote Ping, Traceroute MIB (RFC2925) Support TP-Link private MIBs RMON MIB(RFC1757, rmon 1,2,3,9) |
| Protocollen | |
|---|---|
| Management protocols | SNMPv1/v2c/v3 |
| IPv4 & IPv6 features | IPv6 Telnet,IPv6 ping,IPv6 tracert |
| Data-uitwisseling | |
|---|---|
| Switching capacity | 16 |
| MAC address table | 8000 |
| Jumbo frames support | Ja |
| Jumbo frames | 9000 |
| Forwarding rate | 11.9 |
| Packet buffer memory | 4.1 |
| Number of queues | 8 |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Ja |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Multicast-functies | |
|---|---|
| Multicast support | Ja |
