TP-Link TL-SF1016D Unmanaged Fast Ethernet (10/100) Zwart

What This Product Does
The TL-SF1016D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1016D can save the power consumption and 70% of the packaging material can be recycled, making it an eco-friendly solution for your business network.

High Performance
TL-SF1016D Fast Ethernet Switch provides 16 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1016D forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1016D work reliably.

TP-LINK Green Technology
This new generation TL-SF1016D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 70% of the packaging material can be recycled.

Easy to Use
The auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.
  • Switch type
  • 10G support
  • Full duplex
  • Auto-negotiation
  • Power over Ethernet (PoE)
  • Store-and-forward
  • Auto MDI/MDI-X
  • Basic switching RJ-45 Ethernet ports quantity
  • Basic switching RJ-45 Ethernet ports type
  • Fast Ethernet (copper) ports quantity
  • Power connector
  • Networking standards
  • Copper ethernet cabling technology
  • Half duplex
  • Flow control support
  • Ethernet LAN data rates
  • MAC address auto-learning supported
  • Switching capacity
  • MAC address table
  • Rack mounting
  • Stackable
  • Product colour - Black
  • LED indicators
  • Wall mountable
  • Fanless
  • Minimum system requirements
  • Power source
  • Power supply included
  • DC input voltage
  • Input current
  • Power consumption (max)
  • Operating temperature (T-T)
  • Storage temperature (T-T)
  • Operating relative humidity (H-H)
  • Storage relative humidity (H-H)
  • Heat dissipation
  • Width
  • Depth
  • Height
  • User guide
  • AC adapter included
  • Package type
  • Package width
  • Package depth
  • Package height
  • Package weight
  • Sustainability compliance
  • Compliance certificates
Toevoegen aan verlanglijst
Prijs
33,16 € 33,16 €

Algemene voorwaarden
Geld-terug-garantie van 30 dagen
Verzending: 2-3 werkdagen

Specificaties

Design
Rack mounting Ja
Stackable Geen
Product colour Black
LED indicators Ja
Wall mountable Ja
Netwerk
10G support Geen
Full duplex Ja
Auto-negotiation Ja
Auto MDI/MDI-X Ja
Networking standards IEEE 802.3u,IEEE 802.3x
Copper ethernet cabling technology 100BASE-TX,10BASE-T
Half duplex Ja
Flow control support Ja
Ethernet LAN data rates 10,100
MAC address auto-learning supported Ja
Poorten & interfaces
Basic switching RJ-45 Ethernet ports quantity 16
Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity 16
Power connector DC-in jack
Energie
Power source DC
Power supply included Ja
DC input voltage 9
Input current 0.6
Power consumption (max) 3.23
Gewicht en omvang
Width 200
Depth 142
Height 40
Inhoud van de verpakking
User guide Ja
Eisen aan de omgeving
Operating temperature (T-T) 0 - 40
Storage temperature (T-T) -40 - 70
Operating relative humidity (H-H) 10 - 90
Storage relative humidity (H-H) 5 - 90
Heat dissipation 11.01
Certificaten
Compliance certificates CE,Federal Communications Commission (FCC),RoHS
Duurzaamheid
Sustainability compliance Ja
Verpakking
AC adapter included Ja
Package type Box
Package width 223
Package depth 285
Package height 68
Package weight 590
Prestatie
Fanless Ja
Minimum system requirements Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, MAC OS, NetWare, UNIX, Linux
Beheerfuncties
Switch type Unmanaged
Data-uitwisseling
Store-and-forward Ja
Switching capacity 3.2
MAC address table 2000
Power over Ethernet (PoE)
Power over Ethernet (PoE) Geen
