CPU Water Cooler
Outstanding cooling performance through liquid cooling. ARCTIC's Premium Liquid Freezer range offers impressively high performance at moderate prices without the complexity of conventional CPU water coolers. Completely maintenance-free, the all-in-one cooler with various models for smaller and larger cases covers all the most important current CPU sockets.
Outstanding cooling performance through liquid cooling. ARCTIC's Premium Liquid Freezer range offers impressively high performance at moderate prices without the complexity of conventional CPU water coolers. Completely maintenance-free, the all-in-one cooler with various models for smaller and larger cases covers all the most important current CPU sockets.
Specifications
| Design | |
|---|---|
| Product colour | Black |
| Number of fans | 3 |
| Fan diameter | 120 |
| Illumination colour | Multi |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Illumination LED | Yes |
| LED connector type | 3-pin |
| Processor | |
|---|---|
| Supported processor sockets | LGA 1851,LGA 1700,Socket AM4,Socket AM5 |
| Energie | |
|---|---|
| Fan voltage | 12 |
| Ledvoltage | 5 |
| Pomp voltage | 12 |
| Pomp stroom | 350 |
| Fan current | 0.33 |
| Gewicht en omvang | |
|---|---|
| Width | 120 |
| Depth | 398 |
| Height | 66 |
| Weight | 2005 |
| Radiator width | 120 |
| Radiator depth | 398 |
| Radiator height | 38 |
| Tube length | 450 |
| VRM-ventilatordiameter | 91 |
| Slang diameter | 12.4 |
| Binnendiameter van buis | 6 |
| Fan dimensions (W x D x H) | 120 x 120 x 25 |
| Kenmerken | |
|---|---|
| Quantity per pack | 1 |
| Type | Liquid cooling kit |
| Eisen aan de omgeving | |
|---|---|
| Operating temperature (T-T) | 0 - 40 |
| Verpakking | |
|---|---|
| Package width | 167 |
| Package depth | 414 |
| Package height | 142 |
| Package weight | 2450 |
| Package type | Box |
| Overige specificaties | |
|---|---|
| Fan connector | 4-pin |
| Prestatie | |
|---|---|
| Suitable location | Processor |
| Airflow | 131 |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Pump motor speed (min) | 800 |
| Pump motor speed (max) | 2800 |
| Fan speed (min) | 600 |
| Fan speed (max) | 3000 |
| Fan static pressure | 6.9 |
| VRM-ventilatorsnelheid (min) | 400 |
| VRM-ventilatorsnelheid (max) | 2500 |
| Koeling | |
|---|---|
| Maximum airflow | 77 |
| Pulse-width modulation (PWM) support | Yes |
