Impressive lighting and airflow
Pure Base 501 DX Black is an impressively illuminated be quiet! ATX case with compact dimensions and high airflow for any application. Elevate your system with the elegant ARGB lighting and relish the show.
Pure Base 501 DX Black is an impressively illuminated be quiet! ATX case with compact dimensions and high airflow for any application. Elevate your system with the elegant ARGB lighting and relish the show.
Specifications
| Design | |
|---|---|
| Form factor | Midi Tower |
| Product colour | Black |
| Illumination | Y |
| Illumination colour | Multi |
| Supported motherboard form factors | ATX,Micro ATX,Mini-ATX |
| Number of 3.5" bays | 2 |
| Number of 2.5" bays | 5 |
| Number of expansion slots | 7 |
| Side window | Y |
| Illumination location | Front |
| Anti-dust filter | Y |
| Maximum graphics card length | 368 |
| Maximum PSU length | 200 |
| Volume | 24.4 |
| Opslagmedia | |
|---|---|
| Supported HDD sizes | 2.5,3.5 |
| Poorten & interfaces | |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Audio output | Y |
| Audio input | Y |
| Energie | |
|---|---|
| Power supply included | N |
| Gewicht en omvang | |
|---|---|
| Width | 231 |
| Depth | 450 |
| Height | 463 |
| Weight | 7800 |
| Kenmerken | |
|---|---|
| Type | PC |
| Material | Acrylonitrile Butadiene Styrene (ABS),Glass,Steel |
| Certificaten | |
|---|---|
| Compliance certificates | CE,RoHS,UKCA,WEEE |
| Duurzaamheid | |
|---|---|
| Sustainability certificates | Triman |
| Verpakking | |
|---|---|
| Package width | 292 |
| Package depth | 518 |
| Package height | 503 |
| Package weight | 9200 |
| Overige specificaties | |
|---|---|
| Fan connector | 4-pin |
| Prestatie | |
|---|---|
| Warranty period | 3 |
| Power voorraad | |
|---|---|
| Supported power supply form factors | ATX,PS2 |
| Koeling | |
|---|---|
| Front fans installed | 1x 140 mm |
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120,140 |
| Rear fans installed | 1x 140 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120,140 |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120,140 |
| Maximum airflow | 57.4 |
| Maximum air pressure | 0.96 |
| Liquid cooling capability | Y |
| Front radiator sizes supported | 120,140,240,280,360 |
| Rear radiator sizes supported | 120,140 |
| Top radiator sizes supported | 120,240 |
| Noise level (high speed) | 21.9 |
| Fan rated current | 0.06 |
| Top fans installed | 1x 140 mm |
| Fan rated voltage | 5 - 13.2 |
| Fan power consumption | 3.6 |
| Pulse-width modulation (PWM) support | Yes |
