Superior Wi-Fi Speeds and Performance
QCA enterprise class chipsets, dedicated high-power amplifier and professional antenna along with the latest generation 802.11ac Wave 2 MU-MIMO technology, ensure superior 1750 Mbps Wi-Fi speeds and long-range coverage over 2.4GHz and 5GHz wireless bands.
Seamless Roaming
802.11k/802.11v seamless roaming switches clients automatically to the access point with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.
Secure Guest Network with Facebook W-Fi and SMS Login
Guest Network provides secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Multiple PoE Options for Easy Installation
EAP245 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.
Free Cloud Centralized Management
- Anytime, Anywhere
Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smartphone or tablet.
QCA enterprise class chipsets, dedicated high-power amplifier and professional antenna along with the latest generation 802.11ac Wave 2 MU-MIMO technology, ensure superior 1750 Mbps Wi-Fi speeds and long-range coverage over 2.4GHz and 5GHz wireless bands.
Seamless Roaming
802.11k/802.11v seamless roaming switches clients automatically to the access point with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.
Secure Guest Network with Facebook W-Fi and SMS Login
Guest Network provides secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Multiple PoE Options for Easy Installation
EAP245 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.
Free Cloud Centralized Management
- Anytime, Anywhere
Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smartphone or tablet.
Specifications
| Design | |
|---|---|
| Product colour | White |
| LED indicators | Power |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Reset button | Y |
| Plaatsing | Ceiling,Wall |
| Netwerk | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 |
| VLAN support | Y |
| Rate limiting | Y |
| Cabling technology | 10/100/1000Base-T(X) |
| Poorten & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Energie | |
|---|---|
| Power consumption (typical) | 12.7 |
| Voltage | 12 |
| Output current | 1.5 |
| Type Power over Ethernet (PoE) ondersteunt | Active PoE,Passive PoE |
| Beveiliging | |
|---|---|
| Access Control List (ACL) | Y |
| Security algorithms | 64-bit WEP,128-bit WEP,152-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
| MAC address filtering | Y |
| Service Set Identifier (SSID) functies | Multiple SSIDs |
| Aantal SSID-ondersteuningen | 16 |
| Port-based Network Access Control (PNAC) | Yes |
| Gewicht en omvang | |
|---|---|
| Width | 180 |
| Depth | 180 |
| Height | 47.5 |
| Inhoud van de verpakking | |
|---|---|
| Cables included | AC |
| Quick start guide | Y |
| Mounting kit | Y |
| Inclusief PoE-adapter | Yes |
| Kenmerken | |
|---|---|
| Quantity per pack | 1 |
| Maximum data transfer rate | 1750 |
| 2,4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Maximale overdrachtssnelheid van gegevens (2.4 GHz) | 450 |
| Maximale overdrachtssnelheid van gegevens (5 GHz) | 1300 |
| MIMO | Y |
| MIMO type | Multi User MIMO |
| Airtime Fairness (ATF) | Yes |
| BeamForming | Yes |
| Frequency band | 2.4 - 5 |
| Automatische kanaalselectie | Yes |
| Automatisch scannen kanalen | Yes |
| Bandbreedteaansturing | Yes |
| Transmitting power (CE) | 20 - 23 |
| Zendvermogen (FCC) | 24 |
| Wifi Multimedia (WMM)/(WME) | Yes |
| Draadloze isolatie | Yes |
| Eisen aan de omgeving | |
|---|---|
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 90 |
| Certificaten | |
|---|---|
| Compliance certificates | CE,Federal Communications Commission (FCC),RoHS |
| Duurzaamheid | |
|---|---|
| Sustainability compliance | Y |
| Verpakking | |
|---|---|
| Package width | 228 |
| Package depth | 340 |
| Package height | 65 |
| Package weight | 1180 |
| Logistieke gegevens | |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Prestatie | |
|---|---|
| Compatible operating systems | Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10 |
| Beheerfuncties | |
|---|---|
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Syslog | Yes |
| Protocollen | |
|---|---|
| Management protocols | HTTP/HTTPS |
| Antenne | |
|---|---|
| Antenna type | Internal |
| Antenne versterkingsniveau (max) | 4 |
| Type antennerichting | Omni-directional |
| Antennefuncties | Integrated antenna |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Y |
