High-Density Connectivity with 4× Increased Capacity
OFDMA* and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.
Advanced Wi-Fi Speed with 4 Spatial Streams
The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 1775 Mbps (1201 Mbps on a 5 GHz band and 574 Mbps on a 2.4 GHz band). With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications.
Omada SDN—Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.
Seamless Roaming
802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.
Secure Guest Network with Facebook Wi-Fi and SMS Login
Guest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.
OFDMA* and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.
Advanced Wi-Fi Speed with 4 Spatial Streams
The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 1775 Mbps (1201 Mbps on a 5 GHz band and 574 Mbps on a 2.4 GHz band). With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications.
Omada SDN—Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.
Seamless Roaming
802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.
Secure Guest Network with Facebook Wi-Fi and SMS Login
Guest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.
Specifications
| Design | |
|---|---|
| Product colour | White |
| LED indicators | Y |
| Reset button | Y |
| Plaatsing | Ceiling,Wall |
| Netwerk | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 |
| Flow control support | Y |
| VLAN support | Y |
| Rate limiting | Y |
| Cabling technology | 10/100/1000Base-T(X) |
| Poorten & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Y |
| Energie | |
|---|---|
| DC voltage bereik | 12 |
| Type Power over Ethernet (PoE) ondersteunt | Active PoE,Passive PoE |
| Beveiliging | |
|---|---|
| Access Control List (ACL) | Y |
| Security algorithms | SNMP,SNMPv2,SNMPv3,SSH,WEP,WPA-Enterprise,WPA-PSK,WPA2-Enterprise,WPA2-PSK,WPA3,WPA3-PSK |
| MAC address filtering | Y |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Gewicht en omvang | |
|---|---|
| Width | 160 |
| Depth | 160 |
| Height | 33 |
| Inhoud van de verpakking | |
|---|---|
| Quick start guide | Y |
| Mounting kit | Y |
| Kenmerken | |
|---|---|
| Quantity per pack | 1 |
| Maximum data transfer rate | 1201 |
| 2,4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Maximale overdrachtssnelheid van gegevens (2.4 GHz) | 574 |
| Maximale overdrachtssnelheid van gegevens (5 GHz) | 1201 |
| MIMO | Y |
| MIMO type | Multi User MIMO |
| Airtime Fairness (ATF) | Yes |
| BeamForming | Yes |
| Frequency band | 2.4 - 5 |
| Automatische kanaalselectie | Yes |
| Automatisch scannen kanalen | Yes |
| Spread spectrum methode | OFDMA |
| Fit AP-modusfuncties | Mesh networking |
| Bandbreedteaansturing | Yes |
| Transmitting power (CE) | 20/23 |
| Zendvermogen (FCC) | 23 |
| Eisen aan de omgeving | |
|---|---|
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 90 |
| Certificaten | |
|---|---|
| Certification | CE, FCC, RoHS |
| Verpakking | |
|---|---|
| Package type | Box |
| Beheerfuncties | |
|---|---|
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Syslog | Yes |
| Firmware upgradeable | Y |
| Antenne | |
|---|---|
| Antenna type | Internal |
| Type antennerichting | Omni-directional |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Y |
