The NETGEAR GS108Tv3 8-Port Gigabit Smart Managed Pro Switch with Cloud Management is fanless, supporting perfectly silent desktop operation or wall mounting. The GS108Tv3 Smart Managed Pro Switch offers an easy-to-use, Web browser-based management GUI with configurable L2 network features like VLANs and QoS for wireless converged networks and mobility. This switch also comes with NETGEAR Insight Cloud management activation (free for the first two devices) for anytime remote management and monitoring through an intuitive app or Cloud Portal. Advanced features such as IPv4 Layer 2+ static routing,IPv6 management, ACL, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks. The GS108Tv3 features Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings and is backed by NETGEAR ProSAFE Limited Lifetime Warranty and 24/7 support including lifetime chat.
Specificaties
| Design | |
|---|---|
| Kleur van het product | Grey |
| LED-indicatoren | Activity,LAN,Link,PoE,Power,Speed |
| Stackable | Geen |
| Processor | |
|---|---|
| Processor frequency | 500 |
| Geheugen | |
|---|---|
| Internal memory | 128 |
| Netwerk | |
|---|---|
| Supported network protocols | HTTP, HTTPS |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-TX |
| Link aggregation | Ja |
| Networking standards | IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3x |
| Full duplex | Ja |
| Flow control support | Ja |
| Spanning tree protocol | Ja |
| Port mirroring | Ja |
| Broadcast storm control | Ja |
| Rate limiting | Ja |
| Number of VLANs | 64 |
| MAC address auto-learning supported | Ja |
| Poorten & interfaces | |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | DC-in jack |
| Energie | |
|---|---|
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Power supply included | Ja |
| DC input voltage | 54 |
| Power consumption (max) | 5.5 |
| Input current | 1.25 |
| Beveiliging | |
|---|---|
| DHCP features | DHCP client |
| Access Control List (ACL) | Ja |
| IGMP snooping | Ja |
| Security algorithms | 802.1x RADIUS |
| MAC address filtering | Ja |
| Toegangsbeheerlijst (ACL) IPv6-vermeldingen | 100 |
| Gewicht en omvang | |
|---|---|
| Breedte | 158 |
| Diepte | 101 |
| Hoogte | 27 |
| Gewicht | 430 |
| Inhoud van de verpakking | |
|---|---|
| Manual | Ja |
| Eisen aan de omgeving | |
|---|---|
| Bedrijfstemperatuur (T-T) | 0 - 40 |
| Temperatuur bij opslag | -20 - 70 |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 95 |
| Luchtvochtigheid bij opslag | 0 - 95 |
| Hoogte, in bedrijf | 0 - 3000 |
| Hoogte bij opslag | 0 - 3000 |
| Heat dissipation | 18.66 |
| Certificaten | |
|---|---|
| Certificering | CE, FCC, VCCI Class B, C-Tick |
| Verpakking | |
|---|---|
| Breedte verpakking | 226 |
| Diepte verpakking | 270 |
| Hoogte verpakking | 64 |
| Gewicht verpakking | 780 |
| Package type | Box |
| Logistieke gegevens | |
|---|---|
| Code geharmoniseerd systeem (HS) | 85176990 |
| Hoeveelheid per (buitenste) hoofdverpakking | 6 |
| Master (outer) case gross weight | 5490 |
| Master (outer) case width | 214 |
| Master (outer) case length | 474 |
| Master (outer) case height | 312 |
| Prestatie | |
|---|---|
| Flash memory | 32 |
| Mean time between failures (MTBF) | 2388657 |
| Memory type | RAM |
| Beheerfuncties | |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Ja |
| Firmware upgradeable | Ja |
| Protocollen | |
|---|---|
| Management protocols | SNMP |
| Wissel protocols | SNMP |
| Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data-uitwisseling | |
|---|---|
| Switching capacity | 16 |
| MAC address table | 8000 |
| Jumbo frames support | Ja |
| Packet buffer memory | 0.5 |
| Store-and-forward | Ja |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Geen |
| Multicast-functies | |
|---|---|
| Multicast support | Ja |
| IPv4-multicast-vermeldingen | 32 |
| Number of multicast groups filtered | 256 |
