Get the Higher DSL Speeds Cost-Effectively
The integrated DSL port supports VDSL2/ADSL2+/ADSL2/ADSL connections. Compatibility with the leading ISPs provides ideal IP-based connections for any small business.
Versatile Connectivity
DR3650v is compatible with Super VDSL (VDSL2 Profile 35b), Ethernet access, and 4G/3G USB modems. Its Gigabit LAN/WAN port accepts connections from cable or fiber modems, and the USB 3.0 port supports 4G/3G dongles for a solid main or backup internet connection.
Software Defined Networking (SDN) with Cloud Access
Centralized cloud management for Omada gateways, switches, and access points across multiple sites, with the Omada cloud-based controller offering the Essentials version of cloud services for free, reducing maintaince costs.
High-Security and High-Performance VPN
IPSec/PPTP/L2TP/GRE/WireGuard/ Open VPN/ SSL VPN easily builds secure VPN tunnels for secure Internet browsing, communication between different branches, or enabling remote work or study from home.
The integrated DSL port supports VDSL2/ADSL2+/ADSL2/ADSL connections. Compatibility with the leading ISPs provides ideal IP-based connections for any small business.
Versatile Connectivity
DR3650v is compatible with Super VDSL (VDSL2 Profile 35b), Ethernet access, and 4G/3G USB modems. Its Gigabit LAN/WAN port accepts connections from cable or fiber modems, and the USB 3.0 port supports 4G/3G dongles for a solid main or backup internet connection.
Software Defined Networking (SDN) with Cloud Access
Centralized cloud management for Omada gateways, switches, and access points across multiple sites, with the Omada cloud-based controller offering the Essentials version of cloud services for free, reducing maintaince costs.
High-Security and High-Performance VPN
IPSec/PPTP/L2TP/GRE/WireGuard/ Open VPN/ SSL VPN easily builds secure VPN tunnels for secure Internet browsing, communication between different branches, or enabling remote work or study from home.
Specificaties
| Design | |
|---|---|
| Kleur van het product | Black |
| LED-indicatoren | DSL,LAN,USB,WLAN |
| Product type | Tabletop router |
| Reset button | Ja |
| Indication light | Ja |
| Wall mountable | Ja |
| Geheugen | |
|---|---|
| Internal memory type | DDR4 |
| Netwerk | |
|---|---|
| Ethernet LAN | Ja |
| Ethernet LAN data rates | 10,100,1000 |
| Dynamic DNS (DDNS) | Ja |
| Load balancing system | Ja |
| Ethernet LAN interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x |
| Op beleid gebaseerde routering | Ja |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Poortactivering | Ja |
| VPN eigenschappen | IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE/SSL |
| Poorten & interfaces | |
|---|---|
| USB-poort | Ja |
| Ethernet LAN (RJ-45) ports | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| RJ-11 ports kwantiteit | 3 |
| DC-in jack | Ja |
| Energie | |
|---|---|
| Voltage | 12 |
| Power source type | AC |
| Output current | 3.3 |
| Beveiliging | |
|---|---|
| Network address translation (NAT) | Ja |
| Access Control List (ACL) | Ja |
| Security algorithms | WPA-Enterprise,WPA-Personal,WPA2-Enterprise,WPA2-Personal,WPA3-Enterprise,WPA3-Personal |
| Toegang voor gasten | Ja |
| URL- filtering | Ja |
| DMZ support | Ja |
| NAT functionality | One-to-One NAT Multi-Net NAT Virtual Server Port Triggering1 NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG UPnP |
| Gewicht en omvang | |
|---|---|
| Breedte | 226 |
| Diepte | 131.2 |
| Hoogte | 35 |
| Inhoud van de verpakking | |
|---|---|
| Meegeleverde kabels | LAN (RJ-45),Phone |
| AC adapter included | Ja |
| Antenne inbegrepen | Ja |
| Eisen aan de omgeving | |
|---|---|
| Bedrijfstemperatuur (T-T) | 0 - 40 |
| Temperatuur bij opslag | -40 - 70 |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 |
| Luchtvochtigheid bij opslag | 5 - 90 |
| Prestatie | |
|---|---|
| Built-in FTP server | Ja |
| Detachable antenna(s) | Ja |
| WAN-verbinding | |
|---|---|
| Ethernet WAN | Ja |
| DSL WAN | Ja |
| SIM-kaartsleuf | Geen |
| 3G/4G USB modem compatibiliteit | Ja |
| Type WAN-aansluiting | RJ-45 |
| Draadloos LAN | |
|---|---|
| WLAN gegevensoverdrachtsnelheid (max) | 2402 |
| WLAN data transfer rate (first band) | 574 |
| WLAN gegevensoverdrachtsnelheid (tweede band) | 2402 |
| DSL-eigenschappen | |
|---|---|
| ADSL2+ | Ja |
| ADSL | Ja |
| ADSL2 | Ja |
| VDSL2 | Ja |
| Beheerfuncties | |
|---|---|
| Quality of Service (QoS) support | Ja |
| Web-based management | Ja |
| System event log | Ja |
| MU-MIMO-technologie | Ja |
| Protocollen | |
|---|---|
| DHCP server | Ja |
| Universal Plug and Play (UPnP) | Ja |
| DHCP client | Ja |
| Stemcodecs | G.711a,G.711ulaw,G.722,G.726,G.729ab |
| Antenne | |
|---|---|
| Antenna design | External |
| Antenne versterkingsniveau (max) | 4.5 |
| Antennas quantity | 3 |
| Data-uitwisseling | |
|---|---|
| Static route | Ja |
