Affordable AI-PC in Nano Format Powered by AMD Ryzen™ Zen 4 APU
The Shuttle XPC Barebone NA10H7, part of the XPC nano family, is powered by the AMD Ryzen™ 7-8845HS APU, featuring the cutting-edge Zen 4 microarchitecture. With 8 cores, 16 threads, and AMD Radeon™ 780M graphics, it delivers exceptional performance and is primed for AI-readiness.
The integrated Neural Processing Unit (NPU) achieves 16 TOPS of AI performance, while the combined NPU, CPU, and GPU offer a total of 39 TOPS, enabling demanding AI workloads. Supporting up to 64 GB of DDR5 memory, the NA10H7 also boasts a comprehensive array of I/O options, including four UHD graphics ports and two USB4 ports.
Designed as a cost-effective, high-performance solution for generative AI tasks, the NA10H7 excels in a variety of applications, such as content creation, gaming, entertainment, office work, commerce, and AIoT implementations. With its compact nano chassis and advanced connectivity features, it sets a new standard for affordable AI-PCs.
The Shuttle XPC Barebone NA10H7, part of the XPC nano family, is powered by the AMD Ryzen™ 7-8845HS APU, featuring the cutting-edge Zen 4 microarchitecture. With 8 cores, 16 threads, and AMD Radeon™ 780M graphics, it delivers exceptional performance and is primed for AI-readiness.
The integrated Neural Processing Unit (NPU) achieves 16 TOPS of AI performance, while the combined NPU, CPU, and GPU offer a total of 39 TOPS, enabling demanding AI workloads. Supporting up to 64 GB of DDR5 memory, the NA10H7 also boasts a comprehensive array of I/O options, including four UHD graphics ports and two USB4 ports.
Designed as a cost-effective, high-performance solution for generative AI tasks, the NA10H7 excels in a variety of applications, such as content creation, gaming, entertainment, office work, commerce, and AIoT implementations. With its compact nano chassis and advanced connectivity features, it sets a new standard for affordable AI-PCs.
Specificaties
| Design | |
|---|---|
| Kleur van het product | Black |
| LED-indicatoren | Power |
| Chassis type | 1L sized PC |
| Cooling type | Active |
| Cable lock slot | Ja |
| Cable lock slot type | Kensington |
| Product type | Mini PC (<= 3L) barebone |
| Housing material | Plastic |
| Processor | |
|---|---|
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen 7 |
| Processor model | 8845HS |
| Processor frequency | 3.8 |
| Processor boost frequency | 5.1 |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor generation | AMD Ryzen 8000 Series |
| L3 cache | 16 |
| L2 cache | 8 |
| Geheugen | |
|---|---|
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 2 |
| Memory slots type | SO-DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 5600 |
| Maximum internal memory | 64 |
| Internal memory installed | Geen |
| Memory voltage | 1.1 |
| Non-ECC | Ja |
| Opslagmedia | |
|---|---|
| Storage drive sizes supported | M.2 |
| Storage drives installed | Geen |
| Compatible memory cards | SD |
| Storage drive interface | PCI Express |
| Card reader integrated | Ja |
| NVMe | Ja |
| SSD form factor | M.2 |
| Grafisch | |
|---|---|
| On-board graphics card | Ja |
| On-board graphics card model | AMD Radeon 780M |
| Graphics card family | AMD |
| Number of displays supported | 4 |
| Netwerk | |
|---|---|
| Ethernet LAN | Ja |
| Wi-Fi | Geen |
| LAN controller | Realtek RTL8125B |
| Poorten & interfaces | |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| Ethernet LAN (RJ-45) ports | 2 |
| Combo headphone/mic port | Ja |
| Energie | |
|---|---|
| AC input voltage | 100 - 240 |
| Number of power supply units | 1 |
| AC input frequency | 50/60 |
| Power supply type | External AC adapter |
| AC adapter output voltage | 19 |
| Power supply | 120 |
| AC adapter output current | 6.32 |
| Gewicht en omvang | |
|---|---|
| Breedte | 132 |
| Diepte | 143 |
| Hoogte | 55 |
| Gewicht | 800 |
| Inhoud van de verpakking | |
|---|---|
| Quick start guide | Ja |
| AC adapter included | Ja |
| Power cord included | Ja |
| Eisen aan de omgeving | |
|---|---|
| Bedrijfstemperatuur (T-T) | 0 - 40 |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 |
| Duurzaamheid | |
|---|---|
| Duurzaamheidscertificaten | ENERGY STAR,ErP |
| Logistieke gegevens | |
|---|---|
| Code geharmoniseerd systeem (HS) | 84714900 |
| Prestatie | |
|---|---|
| Trusted Platform Module (TPM) | Ja |
| Trusted Platform Module (TPM) version | 2.0 |
| Built-in processor | Ja |
| Minimale systeemeisen | |
|---|---|
| Windows operating systems supported | Windows 11 x64 |
| Linux operating systems supported | Ja |
| Multimedia | |
|---|---|
| Built-in speaker(s) | Geen |
| Ergonomie | |
|---|---|
| VESA mounting | Ja |
| Opslag-controllers | |
|---|---|
| Supported storage drive types | SSD |
| Aansluitingen achterzijde | |
|---|---|
| Aantal USB4 Gen 2x2 poorten | 2 |
| BIOS | |
|---|---|
| BIOS type | UEFI AMI |
